The Camburg FOX 2.0 Trail Series kit is a suspension system designed for the Ford F-150. It features FOX 2.0 Performance Series IFP Coilovers that provide 0-2 inches of lift and increased wheel travel. These shocks have a durable construction with a zinc plated alloy body, billet aluminum components, and a heat treated alloy steel shaft. The kit also includes uniball upper arms that replace the stock ball-joint, improving wheel travel and strength. The arms have increased caster and a modified camber curve for better alignment and handling. A billet aluminum cover protects the uniball from dirt and contaminants. In the rear, the kit includes FOX 2.0 Performance Series shocks with a larger aluminum body for improved off-road performance. It is important to note that factory 20" wheels may not clear the upper arm and may require a wheel spacer. Aftermarket wheels with the correct offset are recommended for optimal performance and fit. This kit is not compatible with vehicles equipped with Continuously Controlled Damping (CCD) adaptive suspension, BlueCruise or PowerBoost Hybrid engines, or Tremor models. The kit provides 0-2.5" lift in the front, improved ride and handling, and is made in the USA.
Camburg Ford F-150 2wd 21-23 FOX 2.00" Trail Series Kit
GJCN_CAM-110238-UC
$2,818.80 USD
Description
Specifications:
| Description_ASC | [B@1429412c |
| Description_DEF | [B@7860b5f4 |
| Description_DES | [B@5e18b147 |
| Description_EXT | [B@3e5c9935 |
| Description_FAB | [B@60a29ff3 |
| Description_FAB | [B@1d905906 |
| Description_FAB | [B@699417a |
| Description_INV | [B@5cd6f5ad |
| Description_KSW | [B@287fa4c3 |
| Description_LAB | [B@37b880a3 |
| Description_MKT | [B@7b6685bf |
| Description_SHO | [B@10f66ce3 |
| Description_TLE | [B@45fa9b82 |
| Description_TTP | [B@36b4a606 |
| Description_TTP | [B@79b09612 |
| Description_TTP | [B@5a027cb3 |
| Description_TTP | [B@4b35dafa |
| Description_TTP | [B@5822c10c |
| Bushings Included | Yes |
| Coil Spring Color | Silver |
| Coil Spring End 1 Type | Open |
| Coil Spring End 2 Type | Open |
| Coils Quantity Front | 2 |
| Coils Quantity Rear | 0 |
| Grade Type | Performance |
| Maximum Lift | 2.5 |
| Mounting Hardware Included | Yes |
| Shocks Included | Yes |
| Spring Color | Silver |
| Spring Material | Spring Steel |
| Strut(s) Included | Yes |
| Bushing Color | Black |
| Coil Spring Material | Spring Steel |
| Control Arm Color | Black |
| Control Arm Type | Tubular |
| Dust Cover Caps Included | Yes |
| Front Shock Type | 2.0 Performance Series IFP Coilovers |
| Front Springs Included | Yes |
| Hardware Included | Yes |
| Joint Type | Uniball |
| Lift | 2.5 |
| Load Rate | N/A |
| Prop 65 Y/N | No |
| Rear Shock Type | 2.0 |
| Rear Shocks Included | Yes |
| Rear Springs Included | No |
| Shock Brand | FOX |
| Spring Load | N/A |
| Spring Rate | N/A |
| Title | Camburg Engineering 2WD 2021-2024 Ford F-150 Excludes Raptor FOX 2.0 Performance Lift Kit CAM-110238-UC |
