Overview:
To fully take advantage of ICON’s current 2017-2020 F150 Raptor offerings, ICON engineers decided to scrap the OE leaf springs and develop a replacement that addressed a couple issues found in the R&D process. The result is a user-adjustable multi-rate leaf pack that offers a major performance gain for almost every Raptor setup imaginable. To increase the ride quality of the truck and gain additional droop travel, the spring rate was designed to be slightly lighter than factory, which was found to be on the stiff side for smaller, choppier terrain. While most Raptor owners will embrace the improved ride quality this provides, there are those who have outfitted their trucks with a significant amount of weight and require more load carrying capability. Understanding this, ICON engineers designed the leaf pack with an additional leaf (included with kit) that can be exchanged or added to the pack, yielding an additional 20% or 40% spring rate that will work well for heavier vehicles.
Features and Benefits:
- “ICON 1K” tested under rigorous off-road conditions to validate tune, performance, strength, and durability
- Leaf separators and tip inserts reduce noise and friction while increasing ride comfort
- Triple military wrap front eyelet and rear half wrap for increased durability
- Direct bolt-in to OEM spring location makes for an easy install
- 3 user-adjustable spring rates for unique vehicle setups
- Rebound leaf reduces severe axle wrap
Important Notes:
- TECH NOTE: Not compatible with some aftermarket leaf spring shackles. Stock or ICON 1" lowering shackles are recommended. ICON 1" Lowering Shackles, part number 91001, are recommended for most 2021-2024 F-150 applications unless taller lift heights are required.
- TECH NOTE: Compatible with factory shocks on 2017-2020 F-150 Raptor. 2021-2023 F-150 requires ICON rear shock absorbers part numbers 97721P, 97721CP, or 97721EP.
- TECH NOTE: 2017-2020 F-150 Raptor also requires bump stop spacer kit (PN: 95226) if ICON's hydraulic bump stop kit (PN: 95121) is not used
- APPLICATION NOTE #166: If equipped with Dynamic Bending Headlamps and/or OnBoard Scales part # 611081 is also required
- TECH NOTE: Not compatible with F-150 4WD equipped with Continuously Controlled Damping (CCD) suspension
- TECH NOTE: These leaf springs are sold individually. A quantity of 2 are required per vehicle.
- TECH NOTE: Reduction in rear spring rate may reduce accuracy of OnBoard Scales, if equipped
- TECH NOTE: Hardware kit part number 95225H required for installation (sold separately)
- Hardware kit part # 95225H required for installation (sold separately)
